Description
SPECIFICATIONS
MOTOR: Bosch Performance Line CX Smart System,
36 V / 250 W / 85 Nm
DISPLAY: Bosch Kiox 300 colour display with walk assist
BATTERY*: Bosch PowerTube Li-Ion 36 V / 20,1 Ah (750 Wh)
RANGE**: up to 150 km
CHARGER: Bosch, 4A
SHIFTING SYSTEM: 10-G Shimano Deore
Linkglide
SHIFTER: Shimano Deore
CRANKSET: aluminium
SPROCKET: Shimano Deore
GEAR RATIO: front: 38; rear: 11-43
DRIVETRAIN: Shimano CN-LG50
BRAKES: Tektro T535, 4-piston, hydraulic disc brake
BRAKE ROTORS: front: 180 mm, rear: 180 mm
FRONT-LIGHT: Litemove 110, LED
REAR-LIGHT: Spanninga Pimento
FRAME: Integrale 1.6, Aluminium
FORK: Suntour Mobie25 Air, lockout, 15 mm thru axle
TRAVEL FORK: 100 mm
STEM: Concept EX, adjustable
HANDLEBAR: Concept EX Ergo Riser, Concept EX Riser
GRIPS: Ergon GA30
SADDLE: Fizik Terra Aidon
SEATPOST: Patent XXL, suspension
PEDALS: MTB Flat, aluminium, with reflector
RIMS: Rodi TRYP35, with double eyelets
HUBS: front: Shimano Alivio MT400, 15x100 mm
with QR
rear: Shimano Alivio MT400, 12x142 mm
thru axle
TYRES: Schwalbe Smart Sam, 57-584
FENDER: plastic, with edge protector
CARRIER: Racktime System Carrier
KICKSTAND: rear stand, adjustable
LOCK: Abus 4750 frame lock, key removable
PERMISSIBLE
TOTAL WEIGHT: 170 kg
